Cloud SQL for MySQL

Rotating Admin/Regular AWS SQL Database Users with Keeper

Overview

In this guide, you'll learn how to rotate passwords for Google Cloud MySQL Database User and Admin accounts on your GCP environment using Keeper Rotation. Cloud SQL for MySQL is an GCP managed resource where the MySQL Admin Credentials are defined in the PAM Database record type and the configurations of the MySQL Users are defined in the PAM User record type.

To rotate the passwords of Regular Database Users, Keeper connects to the DB instance with the provided admin credentials and executes the necessary SQL statements to change the password.

Prerequisites

This guide assumes the following tasks have already taken place:

• Keeper Secrets Manager is enabled for your role

• Keeper Rotation is enabled for your role

• A Keeper Secrets Manager application has been created

• A Keeper Rotation gateway is already installed, running, and is able to communicate with your GCP MySQL Database

• Your GCP environment is configured per our documentation

1. Set up PAM Database Records

The PAM Database record contains the admin credentials and necessary configurations to connect to the MySQL instance on Google Cloud SQL. Keeper Rotation will use these provided configurations to rotate passwords of regular database user accounts in the MySQL Cloud SQL instance. These provided admin credentials need to also have sufficient database permissions to successfully change the credentials of the database user accounts.

The following table lists all the required fields on the PAM Database Record:

Field	Description
Title	Keeper record title Ex: GCP MySQL Admin
Hostname or IP Address	The Cloud SQL Endpoint
Port	The MySQL Port, for default ports see port mapping i.e. 3306
Use SSL	Must be checked, performs SSL verification before connecting
Login	Admin account username that will perform rotation
Password	Admin account password
Database ID	The AWS DB instance ID
Database Type	mysql
Provider Region	The region your Cloud SQL instance is using. i.e us-central1

This PAM Database Record with the admin credential needs to be in a shared folder that is shared to the KSM application created in the pre-requisites. Only the KSM application needs access to this privileged account, it does not need to be shared with any users

2. Set up PAM Configuration

Note: You can skip this step if you already have a PAM Configuration set up for this environment.

In the left menu of the vault, select "Secrets Manager", then select the "PAM Configurations" tab, and click on "New Configuration". The following table lists all the required fields on the PAM Configuration Record:

Field	Description
Title	Configuration name, example: GCP Workspace Configuration
Environment	Select: Google Cloud
Gateway	Select the Gateway that is configured on the Keeper Secrets Manager application.
Application Folder	Select the Shared folder where the PAM Configuration will be stored. We recommend placing this in a shared folder with the PAM User records.
GCP ID	A unique ID for this instance of Google Cloud. This is only for your reference and can be anything, but its recommended to be kept short Ex: GCP-DepartmentName
Service Account Key	Copy the JSON text of the service account key of the Gateway
Google Workspace Administrator Email	The email address for a Workspace administrator account that can be used to manage passwords for GCP Principals.

For more details on all the configurable fields in the PAM Configuration record, visit this page.

3. Set up PAM User Records

Keeper Rotation will use the credentials in the PAM Database record to rotate the PAM User records on your Google Cloud environment. The PAM User credential needs to be in a shared folder that is shared to the KSM application created in the prerequisites.

The following table lists all the required fields on the PAM User record:

Field	Description
Title	Keeper record title i.e. GCP DB User 1
Login	Case sensitive username of the account being rotated. If the user in the DB user table is in a Host other than %, add the Host value to the user name as USERNAME@HOST
Password	Account password is optional, rotation will set one if blank

4. Configure Rotation on the PAM User records

Select the PAM User record(s) from Step 3, edit the record and open the "Password Rotation Settings".

• Select the desired schedule and password complexity.

• The "Rotation Settings" should use the PAM Configuration setup previously.

• The "Resource Credential" field should select the PAM Database credential setup from Step 1.

• Upon saving, the rotation button will be enabled and available to rotate on demand, or via the selected schedule.

Any user with edit rights to a PAM User record has the ability to setup rotation for that record.
