# Sumo Logic

### Overview

Keeper supports event streaming into Sumo Logic deployments. External logging is real-time, and new events will appear almost immediately. Setup instructions are below.

<figure><img src="https://4290574019-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-LO5CAzpxoaEquZJBpYz%2Fuploads%2Fsv304LLCvy927aTtKz3N%2Fimage.png?alt=media&#x26;token=883350ac-7ab3-4110-8cfb-e076c482c00a" alt=""><figcaption><p>Enter your Sumo Logic HTTP Source Address</p></figcaption></figure>

The Sumo Logic integration requires a single `sync URL`.&#x20;

### Configure an HTTP Logs and Metrics Source[​](https://help.sumologic.com/docs/send-data/hosted-collectors/http-source/logs-metrics/#configure-an-httplogs-and-metrics-source) <a href="#configure-an-httplogs-and-metrics-source" id="configure-an-httplogs-and-metrics-source"></a>

To configure an HTTP Logs and Metrics Source:

1. In Sumo Logic, select **Manage Data > Collection > Collection**.&#x20;
2. In the Collectors page, click **Add Source** next to a Hosted\*\* \*\*Collector.
3. Select **HTTP Logs & Metrics**.&#x20;
4. Enter a **Name** to display for the Source in the Sumo web application. Description is optional.
5. (Optional) For **Source Host** and **Source Category**, enter any string to tag the output collected from the source. (Category metadata is stored in a searchable field called \_sourceCategory.)
6. **SIEM Processing**. This option is present if Cloud SIEM Enterprise (CSE) is enabled. Click the checkbox to to send the logs collected by the source to CSE.
7. **Fields.** Click the **+Add Field** link to define the fields you want to associate, each field needs a name (key) and value.
8. When the URL associated with the source is displayed, copy the URL so you can use it to upload data.
9. When you are finished configuring the Source, click **Save**.
10. **Processing Rules.** Configure any desired filters, such as allowlist, denylist, hash, or mask, as described in Create a Processing Rule. Processing rules are applied to log data, but not to metric data.

<figure><img src="https://4290574019-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-LO5CAzpxoaEquZJBpYz%2Fuploads%2FBMVUZbp2tEGrVijba8Kk%2Fimage.png?alt=media&#x26;token=d5b6f796-161b-4eab-b95a-b69606dca257" alt=""><figcaption><p>HTTP Source Address to Use in your Keeper SIEM Setup</p></figcaption></figure>
