  1. Privileged Access Manager
  2. Password Rotation
  3. Rotation Use Cases
  4. Azure

Azure VM User Accounts

Rotating local and remote user accounts on Azure Virtual Machines with Keeper

PreviousAzure AD UsersNextAzure Managed Database

Last updated 1 month ago

Was this helpful?

Overview

In this guide, you'll learn how to rotate Azure Virtual Machine local and remote user accounts within the Azure environment using KeeperPAM.

Prerequisites

  • PowerShell is available on all Windows machines and bash on all Linux targets

1. Set up PAM Machine Records

Keeper can rotate any local user account on either the Gateway machine or any other machine on the network. A PAM Machine record should be created for every machine. This PAM Machine record will be associated to a linked administrative credential that has the rights to change passwords for users on the machine.

Once a PAM Machine record is created for every machine, a PAM User record needs to be created for each user account that will be rotated.

The following table lists all the required fields that needs to be filled on the PAM Machine records.

Field
Description

Title

Name of the Record e.g. Windows Machine 1

Hostname or IP Address

Machine hostname or IP as accessed by the Gateway, e.g. 10.0.1.4

Port

Typically 5985 or 5986 for WinRM, 22 for SSH

Private PEM Key

Required for SSH if not using a password

Operating System

The VM Operating System: Windows or Linux

SSL Verification

For WinRM, if selected, will use SSL mode port 5986. Ignored for SSH.

2. Set up PAM Configuration

Note: You can skip this step if you already have a PAM Configuration set up for this environment.

Make sure the following items are completed first:

  • PAM Machine records have been created for each target machine

If you are creating a new PAM Configuration, login to the Keeper Vault and select "Secrets Manager", then select the "PAM Configurations" tab, and click on "New Configuration". The following table lists all the required fields that needs to be filled on the PAM Configuration.

Field
Description

Title

Configuration name, example: Azure Demo

Environment

Select: Azure Network

Gateway

Select the Gateway that is configured on the Keeper Secrets Manager application and has network access to the machine configured from step 1

Application Folder

Select the Shared folder where the PAM Configuration will be stored. We recommend placing this in a shared folder with the admin accounts, not the machines.

Azure ID

A unique ID for this instance of Azure. This is for your reference and can be anything, but its recommended to be kept short Ex: Azure-prod

Client ID

The unique Application (client) ID assigned to your app by Azure AD when the application was registered.

Client Secret

The client credentials secret for the Azure application.

Subscription ID

The UUID that identifies your subscription (i.e. Pay-As-You-GO) to use Azure services.

Tenant ID

The UUID of the Azure Active Directory

3. Set up PAM User records

Keeper Rotation will use the credentials linked from the PAM Machine record to rotate the credentials of accounts referenced by the PAM User records.

The following table lists all the required fields that need to be filled on the PAM User record:

Field
Description

Title

Keeper record title i.e. Local User1

Login

Case sensitive username of the account being rotated. The username has to be in one of the following formats: domain\username username@domain

Password

Account password is optional, rotation will set one if blank

4. Configure Rotation on the PAM User records

Select the PAM User record(s) from Step 3, edit the record and open the "Password Rotation Settings".

  • Select the desired schedule and password complexity.

  • The "Rotation Settings" should use the PAM Configuration setup previously.

  • The "Resource Credential" field should select the PAM Machine admin credential specific to this user's machine.

  • Upon saving, the rotation button will be enabled and available to rotate on demand, or via the selected schedule.

Any user with edit rights to a PAM User record has the ability to setup rotation for that record.

Helpful Resources

Service Management

Keeper can automatically update the Windows service account "log on as" credentials for any Windows services running as the PAM User, and restart the service. Keeper will also update the credential of any scheduled task running as that user on the target machine.

See the for a high level overview and getting started with Azure

are configured for your role

A Keeper Secrets Manager has been created

Your Azure environment is per our documentation

A Keeper Rotation is already installed

The Gateway can communicate to the target Windows machine using or

A Keeper Secrets Manager has been created

A Keeper Rotation is already installed, running, and is provisioned in the Keeper Secrets Manager application you created.

For more details on all the configurable fields in the PAM Configuration record, visit this .

To learn more and set up this capability, see the page.
